M1236
More Info |
Specs
Volts: 25.6
Weight: 2.27Kgs / 4.99 lbs
Length: 150mm / 5.91 in
Height: 25mm / 0.98 in
Width: 100mm / 3.94 in
|
Features
- Automatically charge your trolling battery(s) anytime your outboard is running.
- Fully automatic
- Works beautifully with Lithium Pros batteries
|
Volts: 25.6
Weight: 2.27Kgs / 4.99 lbs
Length: 150mm / 5.91 in
Height: 25mm / 0.98 in
Width: 100mm / 3.94 in
Charge Volts (max/alternator): 29.2
Charge Amps (normal/max): 40 |
- Automatically charge your trolling battery(s) anytime your outboard is running.
- Fully automatic
- Works beautifully with Lithium Pros batteries
|
|
|
P440
More Info |
Specs
Volts: 12.8
Weight: 6.6Kgs / 14.52 lbs
PHCA: 400
Reserve Capacity: 92
Watt-Hours: 512
Length: 208mm / 8.19 in
Height: 180mm / 7.09 in
Width: 125mm / 4.92 in
|
Features
- LiFeMgPO4 Chemistry
- More than 2,000 cycles to 80% DOD
- Operating Temperature: -20 ~ 65′C (-4 ~ 149′F)
- Includes the connecting straps, bolts, washers, split washers and cell covers
|
|
Volts: 12.8
Weight: 6.6Kgs / 14.52 lbs
PHCA: 400
Reserve Capacity: 92
Watt-Hours: 512
Length: 208mm / 8.19 in
Height: 180mm / 7.09 in
Width: 125mm / 4.92 in
Amp-hours (Pb Eq)*: 40
Charge Volts (max/alternator): 14.4
Charge Amps (normal/max): 120 |
- LiFeMgPO4 Chemistry
- More than 2,000 cycles to 80% DOD
- Operating Temperature: -20 ~ 65′C (-4 ~ 149′F)
- Includes the connecting straps, bolts, washers, split washers and cell covers
|
|
|
C310
More Info |
Specs
Volts: 12.8
Weight: 0.887Kgs / 1.95 lbs
PHCA: 170
Watt-Hours: 42
Length: 138mm / 5.43 in
Height: 104mm / 4.09 in
Width: 86mm / 3.39 in
|
Features
- Perfect size for many sport bikes
- Only 2 lbs.
- Compact size makes mounting a snap
|
|
Volts: 12.8
Weight: 0.887Kgs / 1.95 lbs
PHCA: 170
Watt-Hours: 42
Length: 138mm / 5.43 in
Height: 104mm / 4.09 in
Width: 86mm / 3.39 in
Amp-hours (Pb Eq)*: 3.3
Charge Volts (max/alternator): 14.2
Charge Amps (normal/max): 14 |
- Perfect size for many sport bikes
- Only 2 lbs.
- Compact size makes mounting a snap
|
| This is the perfect size, capacity, and cranking power for most of todays sport bikes and small-engined cruisers. |
|
|
E100
More Info |
Specs
Length: 144mm / 5.67 in
Height: 66mm / 2.6 in
Width: 47mm / 1.85 in
Requires separate cell boards |
Features
- Distributed system measuring the voltage and temperature of each cell
- CANBus communications
- Video output of pack voltage, pack amperage, and state of charge
- Input voltage: 12~20V, 120mA
- Overvoltage alarm output
- Undervoltage alarm output
- Includes a 500A shunt
- Ground Fault Detection
- Made in the USA
|
|
Length: 144mm / 5.67 in
Height: 66mm / 2.6 in
Width: 47mm / 1.85 in |
- Distributed system measuring the voltage and temperature of each cell
- CANBus communications
- Video output of pack voltage, pack amperage, and state of charge
- Input voltage: 12~20V, 120mA
- Overvoltage alarm output
- Undervoltage alarm output
- Includes a 500A shunt
- Ground Fault Detection
- Made in the USA
|
|
|
P460
More Info |
Specs
Volts: 12.8
Weight: 9.2Kgs / 20.24 lbs
Watt-Hours: 768
Length: 280mm / 11.02 in
Height: 180mm / 7.09 in
Width: 125mm / 4.92 in
Requires a separate BMS |
Features
- LiFeMgPO4 Chemistry
- More than 2,000 cycles to 80% DOD
- Operating Temperature: -20 ~ 65′C (-4 ~ 149′F)
- Includes the connecting straps, bolts, washers, split washers and cell covers
|
|
Volts: 12.8
Weight: 9.2Kgs / 20.24 lbs
Watt-Hours: 768
Length: 280mm / 11.02 in
Height: 180mm / 7.09 in
Width: 125mm / 4.92 in
Amp-hours (Pb Eq)*: 60
Charge Volts (max/alternator): 14.4
Charge Amps (normal/max): 60 |
- LiFeMgPO4 Chemistry
- More than 2,000 cycles to 80% DOD
- Operating Temperature: -20 ~ 65′C (-4 ~ 149′F)
- Includes the connecting straps, bolts, washers, split washers and cell covers
|
|
|
C310-16
More Info |
Specs
Volts: 16
Weight: 1.02Kgs / 2.24 lbs
PHCA: 170
Watt-Hours: 53
Length: 138mm / 5.43 in
Height: 104mm / 4.09 in
Width: 86mm / 3.39 in
|
Features
- Perfect for drag bikes
- 16V at only 2 lbs!
|
|
Volts: 16
Weight: 1.02Kgs / 2.24 lbs
PHCA: 170
Watt-Hours: 53
Length: 138mm / 5.43 in
Height: 104mm / 4.09 in
Width: 86mm / 3.39 in
Amp-hours (Pb Eq)*: 3.3
Charge Volts (max/alternator): 18
Charge Amps (normal/max): 14 |
- Perfect for drag bikes
- 16V at only 2 lbs!
|
|
|
P4100
More Info |
Specs
Volts: 12.8
Weight: 12.8Kgs / 28.16 lbs
Watt-Hours: 1280
Length: 280mm / 11.02 in
Height: 234mm / 9.21 in
Width: 125mm / 4.92 in
Requires a separate BMS |
Features
- LiFeMgPO4 Chemistry
- More than 2,000 cycles to 80% DOD
- Operating Temperature: -20 ~ 65′C (-4 ~ 149′F)
- Includes the connecting straps, bolts, washers, split washers and cell covers
|
|
Volts: 12.8
Weight: 12.8Kgs / 28.16 lbs
Watt-Hours: 1280
Length: 280mm / 11.02 in
Height: 234mm / 9.21 in
Width: 125mm / 4.92 in
Amp-hours (Pb Eq)*: 100
Charge Volts (max/alternator): 14.4
Charge Amps (normal/max): 100 |
- LiFeMgPO4 Chemistry
- More than 2,000 cycles to 80% DOD
- Operating Temperature: -20 ~ 65′C (-4 ~ 149′F)
- Includes the connecting straps, bolts, washers, split washers and cell covers
|
|
|
C375
More Info |
Specs
Volts: 12.8
Weight: 1.56Kgs / 3.43 lbs
PHCA: 375
Watt-Hours: 99
Length: 200mm / 7.87 in
Height: 134mm / 5.28 in
Width: 78mm / 3.07 in
|
Features
- Fast cranking for up to 3.8L engines
- Lightweight! Only 3.44 lbs
- Mount it on its side for a low profile battery solution
- Great for Formula Ford
- Replaces Varley Red Top 15
|
|
Volts: 12.8
Weight: 1.56Kgs / 3.43 lbs
PHCA: 375
Watt-Hours: 99
Length: 200mm / 7.87 in
Height: 134mm / 5.28 in
Width: 78mm / 3.07 in
Amp-hours (Pb Eq)*: 23
Charge Volts (max/alternator): 14.2
Charge Amps (normal/max): 39 |
- Fast cranking for up to 3.8L engines
- Lightweight! Only 3.44 lbs
- Mount it on its side for a low profile battery solution
- Great for Formula Ford
- Replaces Varley Red Top 15
|
| Suitable for cranking up to 3.8L (up to 610 amps), this battery is best suited for the racer who wants the absolute bare minimum of weight–a battery that needs to start the car and no more. Mount this one on it’s side for a low profile of just over 3″ tall! |
|
|
P4200
More Info |
Specs
Volts: 12.8
Weight: 24.9Kgs / 54.78 lbs
Watt-Hours: 2560
Length: 500mm / 19.69 in
Height: 259mm / 10.2 in
Width: 142mm / 5.59 in
Requires a separate BMS |
Features
- LiFeMgPO4 Chemistry
- More than 2,000 cycles to 80% DOD
- Operating Temperature: -20 ~ 65′C (-4 ~ 149′F)
- Includes the connecting straps, bolts, washers, split washers and cell covers
|
|
Volts: 12.8
Weight: 24.9Kgs / 54.78 lbs
Watt-Hours: 2560
Length: 500mm / 19.69 in
Height: 259mm / 10.2 in
Width: 142mm / 5.59 in
Amp-hours (Pb Eq)*: 200
Charge Volts (max/alternator): 14.4
Charge Amps (normal/max): 200 |
- LiFeMgPO4 Chemistry
- More than 2,000 cycles to 80% DOD
- Operating Temperature: -20 ~ 65′C (-4 ~ 149′F)
- Includes the connecting straps, bolts, washers, split washers and cell covers
|
|
|
C545
More Info |
Specs
Volts: 12.8
Weight: 1.54Kgs / 3.39 lbs
PHCA: 545
Watt-Hours: 128
Length: 177mm / 6.97 in
Height: 131mm / 5.16 in
Width: 86mm / 3.39 in
|
Features
- Fast cranking for up to 3.8L engines
- Lightweight! Only 3.38 lbs
|
|
Volts: 12.8
Weight: 1.54Kgs / 3.39 lbs
PHCA: 545
Watt-Hours: 128
Length: 177mm / 6.97 in
Height: 131mm / 5.16 in
Width: 86mm / 3.39 in
Amp-hours (Pb Eq)*: 30
Charge Volts (max/alternator): 14.2
Charge Amps (normal/max): 40 |
- Fast cranking for up to 3.8L engines
- Lightweight! Only 3.38 lbs
|
|
|
L545
More Info |
Specs
Volts: 12.8
Weight: 1.88Kgs / 4.14 lbs
Reserve Capacity: 24
Watt-Hours: 128
Length: 177mm / 6.97 in
Height: 131mm / 5.16 in
Width: 86mm / 3.39 in
Not for engine starting |
Features
- Solid state MOSFET protection system-no mechanical switches!
- Automatic low voltage protection
- Automatic high voltage protection
- Short circuit protection
- Over current protection
|
|
Volts: 12.8
Weight: 1.88Kgs / 4.14 lbs
Reserve Capacity: 24
Watt-Hours: 128
Length: 177mm / 6.97 in
Height: 131mm / 5.16 in
Width: 86mm / 3.39 in
Amp-hours (Pb Eq)*: 30
Charge Volts (max/alternator): 14.2
Charge Amps (normal/max): 30 |
- Solid state MOSFET protection system-no mechanical switches!
- Automatic low voltage protection
- Automatic high voltage protection
- Short circuit protection
- Over current protection
|
| This battery is a drop in for some bikes but it does a great job cranking a V8 too! Dimensionally it is very similar to an Odyssey PC545 and has the same PHCA rating. After that though there is no comparison. This battery is lighter and has substantially more cycle life. |
|
|
L545-16A
More Info |
Specs
Volts: 16
Weight: 2.02Kgs / 4.44 lbs
PHCA: 505
Reserve Capacity: 22
Watt-Hours: 160
Length: 177mm / 6.97 in
Height: 131mm / 5.16 in
Width: 86mm / 3.39 in
|
Features
- Solid state MOSFET protection system-no mechanical switches!
- Automatic low voltage protection
- Automatic high voltage protection
- Short circuit protection
- Over current protection
- Thermal protection
- Fully alternator compatible
|
|
Volts: 16
Weight: 2.02Kgs / 4.44 lbs
PHCA: 505
Reserve Capacity: 22
Watt-Hours: 160
Length: 177mm / 6.97 in
Height: 131mm / 5.16 in
Width: 86mm / 3.39 in
Amp-hours (Pb Eq)*: 30
Charge Volts (max/alternator): 18
Charge Amps (normal/max): 40 |
- Solid state MOSFET protection system-no mechanical switches!
- Automatic low voltage protection
- Automatic high voltage protection
- Short circuit protection
- Over current protection
- Thermal protection
- Fully alternator compatible
|
|
|
C680
More Info |
Specs
Volts: 12.8
Weight: 1.82Kgs / 4 lbs
PHCA: 680
Reserve Capacity: 26
Watt-Hours: 141
Length: 182mm / 7.17 in
Height: 168mm / 6.61 in
Width: 77mm / 3.03 in
|
Features
- Ultra light weight, only 4 lbs.
- Integrated cell balancing
- Common 680 case size fits in tight spaces
|
|
Volts: 12.8
Weight: 1.82Kgs / 4 lbs
PHCA: 680
Reserve Capacity: 26
Watt-Hours: 141
Length: 182mm / 7.17 in
Height: 168mm / 6.61 in
Width: 77mm / 3.03 in
Charge Volts (max/alternator): 14.2
Charge Amps (normal/max): 55 |
- Ultra light weight, only 4 lbs.
- Integrated cell balancing
- Common 680 case size fits in tight spaces
|
| For applications with a 12v alternator, the C680 is well-suited. It weighs less than 5 lbs, yet it has enough strength to crank over a large (450ci +) engine with ease. |
|
|
L680
More Info |
Specs
Volts: 12.8
Weight: 2.02Kgs / 4.44 lbs
PHCA: 680
Reserve Capacity: 26
Watt-Hours: 141
Length: 182mm / 7.17 in
Height: 168mm / 6.61 in
Width: 77mm / 3.03 in
|
Features
- Fast cranking for up to 5.0L engines
- Lightweight! Only 4.5 lbs
- Fully compatible with alternators
- MOSFET protection system-no mechanical switches
- Fully automatic low & high voltage protection
|
|
Volts: 12.8
Weight: 2.02Kgs / 4.44 lbs
PHCA: 680
Reserve Capacity: 26
Watt-Hours: 141
Length: 182mm / 7.17 in
Height: 168mm / 6.61 in
Width: 77mm / 3.03 in
Charge Volts (max/alternator): 14.2
Charge Amps (normal/max): 55 |
- Fast cranking for up to 5.0L engines
- Lightweight! Only 4.5 lbs
- Fully compatible with alternators
- MOSFET protection system-no mechanical switches
- Fully automatic low & high voltage protection
|
| This is the recommended battery for a vast majority of 12v applications. It has enough power to crank engines requiring up to 800 amps, and plenty of reserve capacity for anything from a daily driver to a dedicated track car. |
|
|
T680-16
More Info |
Specs
Volts: 16
Weight: 2.27Kgs / 4.99 lbs
PHCA: 605
Reserve Capacity: 26
Watt-Hours: 176
Length: 182mm / 7.17 in
Height: 168mm / 6.61 in
Width: 77mm / 3.03 in
|
Features
- Internal cell balancing
- Rigid construction
- Full over-charge protection
|
|
Volts: 16
Weight: 2.27Kgs / 4.99 lbs
PHCA: 605
Reserve Capacity: 26
Watt-Hours: 176
Length: 182mm / 7.17 in
Height: 168mm / 6.61 in
Width: 77mm / 3.03 in
Charge Volts (max/alternator): 18
Charge Amps (normal/max): 15 |
- Internal cell balancing
- Rigid construction
- Full over-charge protection
|
| This is the same incredible lithium pack that has been whipping over Pro Mods all year but with only over charge protection. The third post on this battery is for the charger and will disconnect the charger preventing overcharge. See our blog article for more details. Now you can get into a 16V Lithium Pros battery for less $$$ and we guarantee your satisfaction. |
|
|
L30
More Info |
Specs
Volts: 12.8
Weight: 2.33Kgs / 5.13 lbs
PHCA: 680
Reserve Capacity: 26
Watt-Hours: 141
Length: 250mm / 9.84 in
Height: 142mm / 5.59 in
Width: 97mm / 3.82 in
|
Features
- Common size in road racing
- Full battery management system
|
|
Volts: 12.8
Weight: 2.33Kgs / 5.13 lbs
PHCA: 680
Reserve Capacity: 26
Watt-Hours: 141
Length: 250mm / 9.84 in
Height: 142mm / 5.59 in
Width: 97mm / 3.82 in
Amp-hours (Pb Eq)*: 33
Charge Volts (max/alternator): 55
Charge Amps (normal/max): 14.6 |
- Common size in road racing
- Full battery management system
|
| A very popular size, this battery weighs less than 1/3 of most of the lead acid batteries it replaces, yet it offers more performance. |
|
|
L40
More Info |
Specs
Volts: 12.8
Weight: 3.41Kgs / 7.5 lbs
PHCA: 700
Reserve Capacity: 46
Watt-Hours: 256
Length: 250mm / 9.84 in
Height: 192mm / 7.56 in
Width: 97mm / 3.82 in
|
Features
- Common road racing size
- Full MOSFET solid state battery management system
|
|
Volts: 12.8
Weight: 3.41Kgs / 7.5 lbs
PHCA: 700
Reserve Capacity: 46
Watt-Hours: 256
Length: 250mm / 9.84 in
Height: 192mm / 7.56 in
Width: 97mm / 3.82 in
Amp-hours (Pb Eq)*: 60
Charge Volts (max/alternator): 80
Charge Amps (normal/max): 14.6 |
- Common road racing size
- Full MOSFET solid state battery management system
|
| A very popular size, this battery weighs less than 1/3 of most of the lead acid batteries it replaces, yet it offers more performance. |
|
|
C925
More Info |
Specs
Volts: 12.8
Weight: 4.32Kgs / 9.5 lbs
PHCA: 925
Reserve Capacity: 53
Watt-Hours: 265
Length: 165mm / 6.5 in
Height: 125mm / 4.92 in
Width: 176mm / 6.93 in
|
Features
- Ultra light weight, only 9.5 lbs.
- Integrated cell balancing
- Alternator compatible
- Great choice for an entry level 12V lightweight battery!
- Low profile design
|
|
Volts: 12.8
Weight: 4.32Kgs / 9.5 lbs
PHCA: 925
Reserve Capacity: 53
Watt-Hours: 265
Length: 165mm / 6.5 in
Height: 125mm / 4.92 in
Width: 176mm / 6.93 in
Charge Volts (max/alternator): 14.6
Charge Amps (normal/max): 100 |
- Ultra light weight, only 9.5 lbs.
- Integrated cell balancing
- Alternator compatible
- Great choice for an entry level 12V lightweight battery!
- Low profile design
|
|
|
L925
More Info |
Specs
Volts: 12.8
Weight: 4.32Kgs / 9.5 lbs
PHCA: 925
Reserve Capacity: 53
Watt-Hours: 265
Length: 165mm / 6.5 in
Height: 125mm / 4.92 in
Width: 176mm / 6.93 in
Must be recharged once every 5 months when not in use. |
Features
- Solid state MOSFET protection system-no mechanical switches!
- Automatic low voltage protection
- Automatic high voltage protection
- Short circuit protection
- Over current protection
- Thermal protection
- Fully alternator compatible
|
|
Volts: 12.8
Weight: 4.32Kgs / 9.5 lbs
PHCA: 925
Reserve Capacity: 53
Watt-Hours: 265
Length: 165mm / 6.5 in
Height: 125mm / 4.92 in
Width: 176mm / 6.93 in
Charge Volts (max/alternator): 14.6
Charge Amps (normal/max): 100 |
- Solid state MOSFET protection system-no mechanical switches!
- Automatic low voltage protection
- Automatic high voltage protection
- Short circuit protection
- Over current protection
- Thermal protection
- Fully alternator compatible
|
|
|
L925-16A
More Info |
Specs
Volts: 16
Weight: 2.78Kgs / 6.12 lbs
PHCA: 605
Reserve Capacity: 26
Watt-Hours: 176
Length: 165mm / 6.5 in
Height: 125mm / 4.92 in
Width: 176mm / 6.93 in
|
Features
- Solid state MOSFET protection system-no mechanical switches!
- Automatic low voltage protection
- Automatic high voltage protection
- Short circuit protection
- Over current protection
- Thermal protection
- Fully alternator compatible
|
|
Volts: 16
Weight: 2.78Kgs / 6.12 lbs
PHCA: 605
Reserve Capacity: 26
Watt-Hours: 176
Length: 165mm / 6.5 in
Height: 125mm / 4.92 in
Width: 176mm / 6.93 in
Charge Volts (max/alternator): 14.6
Charge Amps (normal/max): 55 |
- Solid state MOSFET protection system-no mechanical switches!
- Automatic low voltage protection
- Automatic high voltage protection
- Short circuit protection
- Over current protection
- Thermal protection
- Fully alternator compatible
|
| Designed for Pro Mod drag racing, this battery has been amazing teams for over a year. Fast cranking, fast recharge times, only 6.2 lbs. What more could you want? |
|
|
L1600A
More Info |
Specs
Volts: 16
Weight: 5.05Kgs / 11.11 lbs
PHCA: 1000
Reserve Capacity: 53
Watt-Hours: 368
Length: 262mm / 10.31 in
Height: 184mm / 7.24 in
Width: 172mm / 6.77 in
|
Features
- Lightweight-16 volts!
- Only 11.2lbs
- Fast cranking-Handles engines up to 900 cu in.
- Fast recharge-less than 90 minutes from 5%SOC
- Fully automatic low voltage protection
- Fully compatible with alternators (18.0V), works fine without one
|
|
Volts: 16
Weight: 5.05Kgs / 11.11 lbs
PHCA: 1000
Reserve Capacity: 53
Watt-Hours: 368
Length: 262mm / 10.31 in
Height: 184mm / 7.24 in
Width: 172mm / 6.77 in
Charge Volts (max/alternator): 18.2
Charge Amps (normal/max): 55 |
- Lightweight-16 volts!
- Only 11.2lbs
- Fast cranking-Handles engines up to 900 cu in.
- Fast recharge-less than 90 minutes from 5%SOC
- Fully automatic low voltage protection
- Fully compatible with alternators (18.0V), works fine without one
|
| The ultimate 16V lightweight racing battery in total loss (no alternator) systems. Each cell is monitored for safety. With 20Ah of capacity (equivalent to 60 Ah of lead acid capacity), you will have enough energy to complete a 100 lap dirt track event. Also, this battery holds a higher voltage near the end of the event, giving you an edge. Being the same size as the TurboStart and the XS Power 16V AGM batteries makes it a drop-in fit. Get one today! |
|
|
M3440-24CK
More Info |
Specs
Volts: 25.6
Weight: 12.57Kgs / 27.65 lbs
Reserve Capacity: 92
Watt-Hours: 1024
Length: 26mm / 1.02 in
Height: 183mm / 7.2 in
Width: 176mm / 6.93 in
Includes a 24V DC charger |
Features
- 24V in ONE battery!
- 92 minutes of reserve capacity
- Fully sealed
- This kit includes the DC charger, waterproof and fully automatic.
- The DC charger recharges the trolling battery from the outboard.
- Flat discharge curve means that the battery will remain strong all day
- Integrated BMS with low voltage, high voltage, overcurrent, and short circuit protection
|
|
Volts: 25.6
Weight: 12.57Kgs / 27.65 lbs
Reserve Capacity: 92
Watt-Hours: 1024
Length: 26mm / 1.02 in
Height: 183mm / 7.2 in
Width: 176mm / 6.93 in
Amp-hours (Pb Eq)*: 40
Charge Volts (max/alternator): 29.2
Charge Amps (normal/max): 40 |
- 24V in ONE battery!
- 92 minutes of reserve capacity
- Fully sealed
- This kit includes the DC charger, waterproof and fully automatic.
- The DC charger recharges the trolling battery from the outboard.
- Flat discharge curve means that the battery will remain strong all day
- Integrated BMS with low voltage, high voltage, overcurrent, and short circuit protection
|
| For your 24V trolling needs, look no further than the M3440-24CK! this is a 24V battery and DC charger all in one kit. The battery has lots of reserve capacity and a flat discharge curve, so your trolling motor will be strong all day long. The M1224 DC charger tops off your trolling battery every time you start the outboard. |
|
|
T1600
More Info |
Specs
Volts: 16
Weight: 4.45Kgs / 9.79 lbs
PHCA: 750
Reserve Capacity: 46
Watt-Hours: 320
Length: 260mm / 10.24 in
Height: 184mm / 7.24 in
Width: 169mm / 6.65 in
|
Features
- Three terminal design with over charge protection
- Only 9.8lbs
- Quick swap in drag racing and drop 20+ pounds.
- Same size as the XS Power and TurboStart 16V.
|
|
Volts: 16
Weight: 4.45Kgs / 9.79 lbs
PHCA: 750
Reserve Capacity: 46
Watt-Hours: 320
Length: 260mm / 10.24 in
Height: 184mm / 7.24 in
Width: 169mm / 6.65 in
Charge Volts (max/alternator): 18.1
Charge Amps (normal/max): 20 |
- Three terminal design with over charge protection
- Only 9.8lbs
- Quick swap in drag racing and drop 20+ pounds.
- Same size as the XS Power and TurboStart 16V.
|
| This is a great and economical way to get into a lithium battery in drag racing without breaking the bank or changing your battery holder. Pull out the old TurboStart and pop this in its place and instantly save at least 32 lbs! |
|
|
L3420
More Info |
Specs
Volts: 12.8
Weight: 4.32Kgs / 9.5 lbs
PHCA: 700
Reserve Capacity: 46
Watt-Hours: 256
Length: 260mm / 10.24 in
Height: 183mm / 7.2 in
Width: 176mm / 6.93 in
|
Features
- Full battery management system.
- Fully compatible with alternators (14.6V max)
- BCI Group 34 size to replace 34, 48, and 49 sizes.
- Available in positive left and right hand.
- Only 9.5 lbs!
- Equivalent to a 60Ah lead acid battery.
|
|
Volts: 12.8
Weight: 4.32Kgs / 9.5 lbs
PHCA: 700
Reserve Capacity: 46
Watt-Hours: 256
Length: 260mm / 10.24 in
Height: 183mm / 7.2 in
Width: 176mm / 6.93 in
Charge Volts (max/alternator): 14.6
Charge Amps (normal/max): 80 |
- Full battery management system.
- Fully compatible with alternators (14.6V max)
- BCI Group 34 size to replace 34, 48, and 49 sizes.
- Available in positive left and right hand.
- Only 9.5 lbs!
- Equivalent to a 60Ah lead acid battery.
|
| This is the best choice for a replacement battery for BCI Group 34, 78, 48, 49, and others. It is a drop in for many Porsche, BMW, Ferrari, Lamborghini, and other exotic cars. With the full battery management system it integrates beautifully with the vehicle’s charging system and can be stored for months at a time. Perfect to reducing overall weight or improving weight balance and lowering center of gravity. |
|
|
L3420R
More Info |
Specs
Volts: 12.8
Weight: 4.32Kgs / 9.5 lbs
PHCA: 700
Reserve Capacity: 46
Watt-Hours: 256
Length: 260mm / 10.24 in
Height: 183mm / 7.2 in
Width: 176mm / 6.93 in
|
Features
- Full battery management system.
- Fully compatible with alternators (14.6V max)
- BCI Group 34 size to replace 34, 48, and 49 sizes.
- Available in positive left and right hand.
- Only 9.5 lbs!
- Equivalent to a 60Ah lead acid battery.
|
|
Volts: 12.8
Weight: 4.32Kgs / 9.5 lbs
PHCA: 700
Reserve Capacity: 46
Watt-Hours: 256
Length: 260mm / 10.24 in
Height: 183mm / 7.2 in
Width: 176mm / 6.93 in
Charge Volts (max/alternator): 14.6
Charge Amps (normal/max): 80 |
- Full battery management system.
- Fully compatible with alternators (14.6V max)
- BCI Group 34 size to replace 34, 48, and 49 sizes.
- Available in positive left and right hand.
- Only 9.5 lbs!
- Equivalent to a 60Ah lead acid battery.
|
| This is the best choice for a replacement battery for BCI Group 34, 48, 49, and others. It is a drop in for many Porsche, BMW, Ferrari, Lamborghini, and other exotic cars. With the full battery management system it integrates beautifully with the vehicle’s charging system and can be stored for months at a time. Perfect to reducing overall weight or improving weight balance and lowering center of gravity. |
|
|
L3400
More Info |
Specs
Volts: 12.8
Weight: 7.05Kgs / 15.51 lbs
PHCA: 1000
Reserve Capacity: 106
Watt-Hours: 589
Length: 260mm / 10.24 in
Height: 183mm / 7.2 in
Width: 176mm / 6.93 in
|
Features
- Full battery management system.
- Fully compatible with alternators (14.6V max)
- BCI Group 34 size to replace 34, 48, and 49 sizes.
- Available in positive left and right hand.
|
|
Volts: 12.8
Weight: 7.05Kgs / 15.51 lbs
PHCA: 1000
Reserve Capacity: 106
Watt-Hours: 589
Length: 260mm / 10.24 in
Height: 183mm / 7.2 in
Width: 176mm / 6.93 in
Charge Volts (max/alternator): 14.6
Charge Amps (normal/max): 184 |
- Full battery management system.
- Fully compatible with alternators (14.6V max)
- BCI Group 34 size to replace 34, 48, and 49 sizes.
- Available in positive left and right hand.
|
| Perfect for cold weather cranking or diesel applications this battery has tons of power. This is the same battery used the NX Diesel Dragster setting records right now. Check it out on YouTube and listen to how this battery cranks that engine. We are confident you will love how it starts yours even in the cold. Doing an EV conversion? This is also a great battery for you too. |
|
|
L3400R
More Info |
Specs
Volts: 12.8
Weight: 7.05Kgs / 15.51 lbs
PHCA: 1000
Reserve Capacity: 106
Watt-Hours: 589
Length: 260mm / 10.24 in
Height: 184mm / 7.24 in
Width: 176mm / 6.93 in
|
Features
- Full battery management system.
- Fully compatible with alternators (14.6V max)
- BCI Group 34 size to replace 34, 48, and 49 sizes.
- Available in positive left and right hand.
- Only 15.5 lbs!
|
|
Volts: 12.8
Weight: 7.05Kgs / 15.51 lbs
PHCA: 1000
Reserve Capacity: 106
Watt-Hours: 589
Length: 260mm / 10.24 in
Height: 184mm / 7.24 in
Width: 176mm / 6.93 in
Charge Volts (max/alternator): 14.2
Charge Amps (normal/max): 184 |
- Full battery management system.
- Fully compatible with alternators (14.6V max)
- BCI Group 34 size to replace 34, 48, and 49 sizes.
- Available in positive left and right hand.
- Only 15.5 lbs!
|
| Perfect for cold weather cranking or diesel applications this battery has tons of power. This is the same battery used the NX Diesel Dragster setting records right now. Check it out on YouTube and listen to how this battery cranks that engine. We are confident you will love how it starts yours even in the cold. Doing an EV conversion? This is also a great battery for you too. |
|
|
C680-16
More Info |
Specs
Volts: 16
Weight: 2.27Kgs / 4.99 lbs
PHCA: 605
Reserve Capacity: 26
Watt-Hours: 176
Length: 182mm / 7.17 in
Height: 168mm / 6.61 in
Width: 77mm / 3.03 in
Superseded to T680-16 |
Features
- Internal cell balancing
- Rigid construction
- Works with alternators (18.0V max)
|
|
Volts: 16
Weight: 2.27Kgs / 4.99 lbs
PHCA: 605
Reserve Capacity: 26
Watt-Hours: 176
Length: 182mm / 7.17 in
Height: 168mm / 6.61 in
Width: 77mm / 3.03 in
Charge Volts (max/alternator): 18.3
Charge Amps (normal/max): 55 |
- Internal cell balancing
- Rigid construction
- Works with alternators (18.0V max)
|
| This is the same incredible lithium pack that has been whipping over Pro Mods all year but without the MOSFET protection system. Is it safe? Sure but you have to follow a few rules. See our blog article for more details. If you can, you can get into a 16V Lithium Pros battery for less $$$ and we guarantee your satisfaction. |
|
|
M3440
More Info |
Specs
Volts: 12.8
Weight: 6.3Kgs / 13.86 lbs
PHCA: 600
Reserve Capacity: 92
Watt-Hours: 512
Length: 260mm / 10.24 in
Height: 183mm / 7.2 in
Width: 176mm / 6.93 in
The Marine battery that floats! |
Features
- Starting and Deep Cycle in ONE battery
- 92 minutes of reserve capacity
- Fully sealed
- Flat discharge curve means that the battery will remain strong all day
- Integrated BMS–low voltage, high voltage, overcurrent, and short circuit protection
- Works great with on-board DC chargers!
- Compare to an Optima Blue Top 34M at 100 RC and 38.5 lbs.
|
|
Volts: 12.8
Weight: 6.3Kgs / 13.86 lbs
PHCA: 600
Reserve Capacity: 92
Watt-Hours: 512
Length: 260mm / 10.24 in
Height: 183mm / 7.2 in
Width: 176mm / 6.93 in
Amp-hours (Pb Eq)*: 40
Charge Volts (max/alternator): 14.6
Charge Amps (normal/max): 40 |
- Starting and Deep Cycle in ONE battery
- 92 minutes of reserve capacity
- Fully sealed
- Flat discharge curve means that the battery will remain strong all day
- Integrated BMS–low voltage, high voltage, overcurrent, and short circuit protection
- Works great with on-board DC chargers!
- Compare to an Optima Blue Top 34M at 100 RC and 38.5 lbs.
|
| The perfect battery to power your boat! Capable of cranking an engine and running all of the extras with ease. The light weight and reserve capacity mean that you can get to your favorite spot faster and fish for longer without worrying about getting stuck or lugging around two heavy lead-acid batteries. |
|
|
M3160
More Info |
Specs
Volts: 12.8
Weight: 6.3Kgs / 13.86 lbs
PHCA: 900
Reserve Capacity: 138
Watt-Hours: 768
Length: 330mm / 12.99 in
Height: 214mm / 8.43 in
Width: 173mm / 6.81 in
So light it floats! |
Features
- Starting and Deep Cycle in ONE battery
- Compare to Optima Blue Top D27M at 140 RC and 53.8 lbs.
- 138 minutes of reserve capacity
- Fully sealed
- Flat discharge curve means that the battery will remain strong all day
- Integrated BMS–low voltage, high voltage, overcurrent, and short circuit protection
- Will crank a Mercury OptiMax Pro XS engine
|
|
Volts: 12.8
Weight: 6.3Kgs / 13.86 lbs
PHCA: 900
Reserve Capacity: 138
Watt-Hours: 768
Length: 330mm / 12.99 in
Height: 214mm / 8.43 in
Width: 173mm / 6.81 in
Amp-hours (Pb Eq)*: 60
Charge Volts (max/alternator): 14.6
Charge Amps (normal/max): 60 |
- Starting and Deep Cycle in ONE battery
- Compare to Optima Blue Top D27M at 140 RC and 53.8 lbs.
- 138 minutes of reserve capacity
- Fully sealed
- Flat discharge curve means that the battery will remain strong all day
- Integrated BMS–low voltage, high voltage, overcurrent, and short circuit protection
- Will crank a Mercury OptiMax Pro XS engine
|
| A great choice for a starting battery for your boat! The weight makes it easy on the back while lugging into and out of the boat, while the capacity and flat discharge curve means it will be strong all day long. Our battery can also live longer being discharged lower, so no more buying a new battery every season! |
|
|
M3180
More Info |
Specs
Volts: 12.8
Weight: 10.3Kgs / 22.66 lbs
PHCA: 1200
Reserve Capacity: 184
Watt-Hours: 1024
Length: 330mm / 12.99 in
Height: 214mm / 8.43 in
Width: 173mm / 6.81 in
|
Features
- Starting and Deep Cycle in ONE battery
- Compare to Optima Blue Top D31M at 155 RC and 59.8 lbs.
- 184 minutes of reserve capacity
- Fully sealed
- Flat discharge curve means that the battery will remain strong all day
- Integrated BMS–low voltage, high voltage, overcurrent, and short circuit protection
- Will crank a Mercury OptiMax Pro XS engine
|
|
Volts: 12.8
Weight: 10.3Kgs / 22.66 lbs
PHCA: 1200
Reserve Capacity: 184
Watt-Hours: 1024
Length: 330mm / 12.99 in
Height: 214mm / 8.43 in
Width: 173mm / 6.81 in
Amp-hours (Pb Eq)*: 80
Charge Volts (max/alternator): 14.6
Charge Amps (normal/max): 80 |
- Starting and Deep Cycle in ONE battery
- Compare to Optima Blue Top D31M at 155 RC and 59.8 lbs.
- 184 minutes of reserve capacity
- Fully sealed
- Flat discharge curve means that the battery will remain strong all day
- Integrated BMS–low voltage, high voltage, overcurrent, and short circuit protection
- Will crank a Mercury OptiMax Pro XS engine
|
| This the battery for the fisherman who wants to fish ALL day. This battery is all we can fit in a standard size case! The extremely high capacity means that you can crank the engine, troll, and run anything electric on the boat for much longer than you could with the competition’s battery. To top it off, this one weighs almost a third of a comparable lead-acid battery! |
|
|
M3110
More Info |
Specs
Volts: 12.8
Weight: 12.31Kgs / 27.08 lbs
PHCA: 1500
Reserve Capacity: 230
Watt-Hours: 1280
Length: 330mm / 12.99 in
Height: 214mm / 8.43 in
Width: 173mm / 6.81 in
|
Features
- Starting and Deep Cycle in ONE battery
- Incredible 230 minutes of reserve capacity!
- Fully sealed
- Flat discharge curve means that the battery will remain strong all day
- Integrated BMS-low voltage, high voltage, overcurrent, and short circuit protection
- Works great with on-board DC chargers!
|
|
Volts: 12.8
Weight: 12.31Kgs / 27.08 lbs
PHCA: 1500
Reserve Capacity: 230
Watt-Hours: 1280
Length: 330mm / 12.99 in
Height: 214mm / 8.43 in
Width: 173mm / 6.81 in
Amp-hours (Pb Eq)*: 100
Charge Volts (max/alternator): 14.6
Charge Amps (normal/max): 100 |
- Starting and Deep Cycle in ONE battery
- Incredible 230 minutes of reserve capacity!
- Fully sealed
- Flat discharge curve means that the battery will remain strong all day
- Integrated BMS-low voltage, high voltage, overcurrent, and short circuit protection
- Works great with on-board DC chargers!
|
|
|
M3440-24
More Info |
Specs
Volts: 25.6
Weight: 10.3Kgs / 22.66 lbs
Reserve Capacity: 92
Watt-Hours: 1024
Length: 260mm / 10.24 in
Height: 183mm / 7.2 in
Width: 176mm / 6.93 in
Requires a 24V charger |
Features
- 92 minutes of reserve capacity
- 24V in ONE battery!
- Fully sealed
- Flat discharge curve means that the battery will remain strong all day
- Integrated BMS–low voltage, high voltage, overcurrent, and short circuit protection.
|
|
Volts: 25.6
Weight: 10.3Kgs / 22.66 lbs
Reserve Capacity: 92
Watt-Hours: 1024
Length: 260mm / 10.24 in
Height: 183mm / 7.2 in
Width: 176mm / 6.93 in
Amp-hours (Pb Eq)*: 40
Charge Volts (max/alternator): 29.2
Charge Amps (normal/max): 40 |
- 92 minutes of reserve capacity
- 24V in ONE battery!
- Fully sealed
- Flat discharge curve means that the battery will remain strong all day
- Integrated BMS–low voltage, high voltage, overcurrent, and short circuit protection.
|
| For your 24V needs, look no further than the M3440-24! This battery has lots of reserve capacity and a flat discharge curve, so your trolling motor will be strong all day long. Combine it with our M1224 DC charger and have a solution that tops your trolling battery off every time you start the outboard. |
|
|
M3160-24
More Info |
Specs
Volts: 25.6
Weight: 13.09Kgs / 28.8 lbs
Reserve Capacity: 138
Watt-Hours: 1536
Length: 330mm / 12.99 in
Height: 214mm / 8.43 in
Width: 173mm / 6.81 in
Requires a 24V charger |
Features
- Troll all day on ONE 24V battery
- 138 minutes of reserve capacity
- Fully sealed
- Flat discharge curve means that the battery will remain strong all day
- Integrated BMS-low voltage, high voltage, overcurrent, and short circuit protection
- Only 29 lbs!
|
|
Volts: 25.6
Weight: 13.09Kgs / 28.8 lbs
Reserve Capacity: 138
Watt-Hours: 1536
Length: 330mm / 12.99 in
Height: 214mm / 8.43 in
Width: 173mm / 6.81 in
Amp-hours (Pb Eq)*: 60
Charge Volts (max/alternator): 29.2
Charge Amps (normal/max): 60 |
- Troll all day on ONE 24V battery
- 138 minutes of reserve capacity
- Fully sealed
- Flat discharge curve means that the battery will remain strong all day
- Integrated BMS-low voltage, high voltage, overcurrent, and short circuit protection
- Only 29 lbs!
|
| If you are looking for a lightweight battery to power a 24V DC trolling motor, this is it! At only 29 lbs it is hard to believe that ONE battery would take you through the day but that is exactly what the M3160-24 can do. Perfect for any marine application where the battery is being carried to the boat. Why pick up to 55 lb batteries when you can have the same run time with less than 1/3 the weight? |
|
|
M3140-36
More Info |
Specs
Volts: 38.4
Weight: 13.09Kgs / 28.8 lbs
Reserve Capacity: 92
Watt-Hours: 1536
Length: 330mm / 12.99 in
Height: 214mm / 8.43 in
Width: 173mm / 6.81 in
Requires a 36V charger |
Features
- Troll with only ONE 36V battery
- 92 minutes of reserve capacity
- Fully sealed
- Flat discharge curve means that the battery will remain strong all day
- Integrated BMS-low voltage, high voltage, overcurrent, and short circuit protection
- Only 29 lbs!
|
|
Volts: 38.4
Weight: 13.09Kgs / 28.8 lbs
Reserve Capacity: 92
Watt-Hours: 1536
Length: 330mm / 12.99 in
Height: 214mm / 8.43 in
Width: 173mm / 6.81 in
Amp-hours (Pb Eq)*: 40
Charge Volts (max/alternator): 43.8
Charge Amps (normal/max): 30 |
- Troll with only ONE 36V battery
- 92 minutes of reserve capacity
- Fully sealed
- Flat discharge curve means that the battery will remain strong all day
- Integrated BMS-low voltage, high voltage, overcurrent, and short circuit protection
- Only 29 lbs!
|
| If you are looking for a lightweight battery to power a 36V DC trolling motor, this is it! At only 29 lbs it is hard to believe that ONE battery can do what THREE Optima 34M batteries can but that is exactly what the M3140-36 can do. Perfect for any marine application where the battery is being carried to the boat. Why pick up three 40 lb batteries when you can have the same run time with less than 1/3 the weight? |
|
|
1012
More Info |
Specs
|
Features
- Constant Current/Constant Voltage method for a fast and complete charge
- Works great with portable generators
- 15A of output!
- Fully automatic
- Includes 30A quick connectors
- Universal input voltage: 110~240VAC
|
|
Charge Volts (max/alternator): 14.5
Charge Amps (normal/max): 15 |
- Constant Current/Constant Voltage method for a fast and complete charge
- Works great with portable generators
- 15A of output!
- Fully automatic
- Includes 30A quick connectors
- Universal input voltage: 110~240VAC
|
|
|
1013
More Info |
Specs
|
Features
- Constant Current/Constant Voltage method for a fast and complete charge
- Works great with portable generators
- 15A of output!
- Fully automatic
- Includes 30A quick connectors
- Universal input voltage: 110~240VAC
|
|
Charge Volts (max/alternator): 18.1
Charge Amps (normal/max): 15 |
- Constant Current/Constant Voltage method for a fast and complete charge
- Works great with portable generators
- 15A of output!
- Fully automatic
- Includes 30A quick connectors
- Universal input voltage: 110~240VAC
|
|
|
1015
More Info |
Specs
|
Features
- Constant Current/Constant Voltage method for a fast and complete charge
- Works great with portable generators
- 25A of output!
- Fully automatic
- Includes 30A quick connectors
- Universal input voltage: 110~240VAC
|
|
Charge Volts (max/alternator): 18.1
Charge Amps (normal/max): 25 |
- Constant Current/Constant Voltage method for a fast and complete charge
- Works great with portable generators
- 25A of output!
- Fully automatic
- Includes 30A quick connectors
- Universal input voltage: 110~240VAC
|
|
|
1014
More Info |
Specs
Volts: 24
|
Features
- Constant Current/Constant Voltage method for a fast and complete charge
- Works great with portable generators
- 12A of output!
- 28.8V for 24V systems
- Fully automatic
- Includes 30A quick connectors
- Universal input voltage: 110~240VAC
|
|
Volts: 24
Charge Volts (max/alternator): 28.8
Charge Amps (normal/max): 12 |
- Constant Current/Constant Voltage method for a fast and complete charge
- Works great with portable generators
- 12A of output!
- 28.8V for 24V systems
- Fully automatic
- Includes 30A quick connectors
- Universal input voltage: 110~240VAC
|
|
|
1011
More Info |
Specs
|
|
|
|
- Constant Current/Constant Voltage method for a fast and complete charge
- Works great with portable generators
- 12A of output!
- 28.8V for 24V systems
- Fully automatic
- Includes 30A quick connectors
- Universal input voltage: 110~240VAC
|
|
|
1008
More Info |
Specs
|
|
|
|
- Constant Current/Constant Voltage method for a fast and complete charge
- Works great with portable generators
- 12A of output!
- 28.8V for 24V systems
- Fully automatic
- Includes 30A quick connectors
- Universal input voltage: 110~240VAC
|
|
|
1016
More Info |
Specs
Volts: 36
|
|
|
Volts: 36
Charge Volts (max/alternator): 43.4
Charge Amps (normal/max): 12 |
- Constant Current/Constant Voltage method for a fast and complete charge
- Works great with portable generators
- 12A of output!
- 28.8V for 24V systems
- Fully automatic
- Includes 30A quick connectors
- Universal input voltage: 110~240VAC
|
|
|
April 24, 2013
0 Comments
